Python Matplotlib Histogram Specify Different Colours For Different Bars
I want to colour different bars in a histogram based on which bin they belong to. e.g. in the below example, I want the first 3 bars to be blue, the next 2 to be red, and the rest
Solution 1:
One way may be similar to approach in other answer:
import numpy as np
import matplotlib.pyplot as plt
fig, ax = plt.subplots()
data = np.random.rand(1000)
N, bins, patches = ax.hist(data, edgecolor='white', linewidth=1)
for i inrange(0,3):
patches[i].set_facecolor('b')
for i inrange(3,5):
patches[i].set_facecolor('r')
for i inrange(5, len(patches)):
patches[i].set_facecolor('black')
plt.show()
Result:
